M.2 NVMe to PCIe x16 Extender

  • F43 5.0
  • F43 5.0
  • F43 5.0
  • F43 5.0
F43 5.0F43 5.0F43 5.0F43 5.0

F43 5.0

  • Product ID:F43SP
  • Interface: M.2 NVMe / PCIe x16
  • Shelf time:2024-05-13
  • Product description: M.2 NVMe to PCIE 5.0 extender riser adapter
  • Product description: ADT PCIe 5.0 M.2 NVMe to x16 riser cable FFC

ADT-Link M.2 NVMe to PCI express x16 Extension Riser Cable

Brand name: ADT-LINK

Product name:M.2 NVMe to PCIe x16 extension cable

Product model: F43SP, F43SP-TL, F43SP-TR,F43SP-TU

Transferspeed:PCIe 5.0 x4, gen5, 128G/bps (Max.)

Wire length: 25cm,50cm

Application: for PCIe x16 Nvidia/AMD Graphics cards to M.2(ultra SSD, M-key) NVMe slot extension

Cable length Description:

The length of the wire refers to the part of the visible wire. It does not include the PCB and the connector. For the wire length, please refer to the figure below.

Accessories description:

A SATA power adapter cable is included with the product, and it must be connected to have 12V power supply.

ADT F43 series Part-Number Description:

F43SP M.2 NVMe to PCIe x16, connector turn 90° extension cable
PCIe 5.0 x4 (128G/bps)
F43SP-TR M.2 NVMe to PCIe x16, cable turn right, connector turn 90° extension cable
PCIe 5.0 x4 (128G/bps)
F43SP-TL M.2 NVMe to PCIe x16, cable turn left, connector turn 90°extension cable
PCIe 5.0 x4 (128G/bps)

Can F43SP Support PCIe 5.0?

The laboratory measurement can achieve full speed of PCIe 5.0,The picture below is the test result of F43SP-50cm

Product advantages

1.The PCB uses a four-layer high-frequency impedance board with advanced design, exquisite workmanship, stable and fast signals, excellent wiring, good isolation, and can reach the PCIe 5.0 standard.

2.The connector is from Amphenol, the shell material is PA10T/LCP, the socket has a durability of 50 Cycles, supports high frequency and complies with RoHS/Free (HF) requirements.

3.It uses an external power supply design, and the cable itself does not provide power, making it safer to use.

4.Using aluminum alloy gaskets, it can effectively block interference and noise, making it strong and durable.

5.FFC wire, flat cable design with full coverage and shielding, thickness only 0.5mm, ultra-soft and ultra-thin.

6.The gold finger is 10µ" gold-plated, resistant to plugging and unplugging, and has better stability.

Installation renderings


Is there any EMI shielding for Cable?
With metal shielding.  The cable uses the latest EMI shielding materials with full cable coverage shielding to prevent the incoming or outgoing of electromagnetic frequencies, minimizing interference and performance degradation, and reducing the weight of the extender.

What is the thickness of the cable? Is it soft? Can it be bent?
The thickness of the cable wire is 0.5mm, so the wire is softer and can be bent or folded.


To open 3D PDF files. Please use Adobe Reader DC software.

FTP: Los Angeles

3D Step & 3D PDF files download http://www.adt.link/download/ADT_F43V5_3D.zip

Schematic files download http://www.adt.link/download/ADT F43SP Cable specification 20240517.pdf

Cable specification files download http://www.adt.link/download/ADT-Cable 24P 5.0 specification.pdf

FTP: Hong Kong

3D Step & 3D PDF files download http://www.adtlink.cn/download/ADT_F43V5_3D.zip

Schematic files download http://www.adtlink.cn/download/ADT F43SP Cable specification 20240517.pdf
