PCIe x1 to PCIe x16 Extender

K13SF K13SL K13VR

Product name: PCIe 4.0 x1 to x16 extension cable
Product model:K13SF K13SL K13TL
Transferspeed:PCIe4.0 x1 , 16G/bps (Max.)
Application: PCIe x16 Capture Card , RAID SSD, LAN, USB cards, extension
Product description: ADT-Link PCI express 4.0 x1 to x16 Extension Riser Cable
INQUIRY

ADT-Link PCI express 4.0 x1 to x16 Extension Riser Cable

Brand name: ADT-LINK

Product name: PCIe 4.0 x1 to x16 extension cable

Product model:K13SF K13SL K13VR

Transferspeed:PCIe4.0 x1 , 16G/bps (Max.)

Wire length:5 ~ 100 cm, the length can be customized

Application: PCIe x16 Capture Card , RAID SSD, LAN, USB cards, extension

ADT K13 series Part-Number Description:

Part-Number	Description	Bandwidth
K13SF	PCI-E x1 to x16 turn 180 degree splint vertical extension cable	PCIe 4.0 x1 (16G/bps)
K13SL	PCI-E x1 to x16 turn 90 degree upright right angle extension cable	PCIe 4.0 x1 (16G/bps)
K13VR	PCI-E x1 to x16 turn 270 degree extension cable	PCIe 4.0 x1 (16G/bps)

Cable length Description:

The length of the wire refers to the part of the visible wire. It does not include the PCB and the connector. For the wire length, please refer to the 5cm blue arrow in the figure below.

Is there any EMI shielding for Cable?

With metal shield. The extender utilizes the latest materials for EMI shielding with five sole flat cables design. This technique allows each cable to be fully covered by electromagnetic interference shielding with conducting polymer to guard against incoming or outgoing emissions of electromagnetic frequencies, minimize disturbance and degradation on performance, and reduce the weight of the extender.
