mPCIe to M.2 NVMe Extender

R64SF

Product ID：R64SF
Interface: mPCIe / M.2 NVMe
Application: Extension
Shelf time：2019-01-10 11:07:19
Product description: ADT-Link mini-PCIe to M.2 key M NVMe Extension Cable extender adapter extension cable
INQUIRY

ADT-Link mini-PCIe to M.2 NVMe Extension Cable

Brand name: ADT-LINK

Product name: mPCIe to M.2 NVMe extension cable

Product model: R64SF

Transfer speed: PCIe 3.0 x1 full speed, 8G/bps (Max.)

Wire length: 3 ~ 100 cm, the length can be customized

Application: M.2 WiFi slot to mPCIe edge extension cable

ADT R64SF Part-Number Description:

Part-Number	Description	Bandwidth
R64SF	mini-PCIe to M.2 NVMe extension cables	PCIe 3.0 x1 (8G/bps Max.)

Cable length Description:

The length of the wire refers to the part of the visible wire. It does not include the PCB and the connector. For the wire length, please refer to the 5cm blue arrow in the figure below.

Q&A:

Is there any EMI shielding for Cable?

The extender utilizes the latest materials for EMI shielding with five sole flat cables design. This technique allows each cable to be fully covered by electromagnetic interference shielding with conducting polymer to guard against incoming or outgoing emissions of electromagnetic frequencies, minimize disturbance and degradation on performance, and reduce the weight of the extender.

What is the thickness of the cable? Is it soft? Can it be bent?
The thickness of the cable wire is 1.4mm, so the wire is softer. The wire can be bent or folded, but do not pull it.
